Tooling & Mold Development Manufacturer in Pune – Faster In-House Die Design for HPDC, GDC & LPDC

The most important decision in any die casting project is not which alloy to use or which machine to run—it is how the tool is designed. The quality of gate placement, venting design, parting line selection, ejector pin layout and thermal management built into the die determines the casting quality, cycle time and surface finish of every component that will ever be produced from it.

Plasma Aluminium Diecasting designs and fabricates all of its tooling in-house at our Pune facility. This is a deliberate, strategic decision. It means our casting engineers and tooling designers work in the same building, speak to each other daily and share the same quality accountability for every component that comes off the line.

If you need die casting tooling developed in Pune—for HPDC, GDC, or LPDC—with short lead times, engineering competence and full lifecycle support, Plasma is the partner to speak to.

Why Tooling Is the Most Critical Investment in Die Casting

Clients sometimes focus on per-unit cost when evaluating a die casting supplier. But tool cost and tool quality are the two factors that determine the long-term economics of the entire programme. A well-designed, properly built tool produces consistent castings, requires minimal maintenance and allows design modifications efficiently.

  • Produces consistent, repeatable castings from the first production run
  • Requires minimal maintenance over its designed tool life (typically 100,000 to 300,000 shots for HPDC steel tooling)
  • Allows design modifications to be made efficiently when engineering changes arise
  • Runs at the planned cycle time without excessive downtime for cleaning, adjustments, or repairs

Our Tooling & Mold Development Services

New Tool Design

We take your component drawing and produce a complete tool design covering parting line selection, gating and runner system, venting and overflow design, ejection system and thermal management. Final tool geometry is verified by CMM inspection before first trials.

Prototype Tooling

For design validation or pre-production verification, we offer prototype tooling in lower-grade steel or aluminium tooling materials, allowing first-article samples to be produced at lower investment before committing to production tool fabrication.

Tool Repair

Existing tools degrade over time through wear, thermal cycling, damage and accidental impact. We handle tool repair and refurbishment for tools currently in service at Plasma as well as tools transferred from other foundries.

Tool Modification

When engineering changes require a modification to the component—a new hole, a changed wall thickness, a relocated boss—the tool must be modified accordingly. Our in-house tooling team handles these changes directly.

Tool Life Management

We maintain detailed shot count records for all tools in production at Plasma. Based on tool design life and shot count, we schedule preventive maintenance interventions before problems appear in production, not after.

Our Tooling Process – From Design to First Shot

  1. Design for Manufacturability (DFM) review: We review the component drawing and identify any features that will cause filling, ejection, or dimensional problems
  2. Tool design: Full tool design including gating, venting, ejection and cooling, reviewed and approved with the client
  3. Tool fabrication: Machining of tool components from specified steel grades on our in-house equipment
  4. Assembly and fitting: Tool assembly, fitting of inserts and ejector pins and verification of parting line closure
  5. CMM verification: Tool cavity dimensions verified against design specification before trial shots
  6. Trial shots: First samples produced, measured fully and reviewed against drawing tolerances
  7. Production release: Tool released for production after first-article approval

Tool Steel Selection for Die Casting

We select tool steel grades based on the casting process and expected production volume:

  • H13 Hot Work Tool Steel: The industry standard for HPDC tooling. Excellent thermal fatigue resistance and toughness for the high-pressure, high-temperature HPDC cycle. Suitable for tool lives of 100,000 to 300,000+ shots.
  • P20 Pre-hardened Steel: Used for GDC and LPDC tooling and for prototype HPDC tooling at lower investment. Lower thermal shock resistance than H13 but more machinable for complex inserts.
  • Aluminium Tooling: Used for prototype and design validation tools where cost and lead time are prioritised over tool life.

In-House Tooling: The Plasma Advantage

When tooling is outsourced to a third-party tool shop, communication between the tool designer, the foundry and the client becomes an engineering game of telephone. With tooling in-house at Plasma:

  • Our casting engineers are involved in tool design decisions from the start
  • Modification requests are turned around in days, not weeks
  • Tool maintenance is scheduled proactively, not reactively
  • There is a single team accountable for both tool quality and casting quality

Tooling Services for Pune, Chakan, Moshi & India

Plasma's tooling and mould development capability is available to clients across Pune, Chakan MIDC, Moshi and nationally. Whether you are starting a new programme and need tooling developed from scratch, or you have existing tools that need repair or modification, our team is ready to engage. Contact Plasma Aluminium Diecasting to discuss your tooling requirement—we will provide a detailed tool design proposal and commercial quotation.

Our Services

Frequently Asked Questions (FAQs)

For standard HPDC and GDC tools, our in - house development timeline from design sign - off to first trial shots is typically 4 to 8 weeks. Complex multi - cavity tools or LPDC tooling with integrated thermal circuits may take 8 to 12 weeks. We provide a specific tooling timeline commitment at the quotation stage.

We use H13 hot work tool steel as our primary grade for HPDC tooling, providing the thermal fatigue resistance and toughness required for the high - pressure, high - temperature HPDC cycle. For GDC, LPDC and prototype tooling, we use P20 pre - hardened steel or aluminium tooling grades depending on the tool life requirement and investment level.

Yes. We handle tool repair, refurbishment and engineering modification for tools transferred from other foundries, provided the tool design documentation is available. Our tooling team will assess the tool condition and provide a repair or modification proposal before committing to the work.

Yes. We offer prototype and soft tooling in lower - cost tool steel or aluminium materials, allowing first - article samples to be produced for design validation at a fraction of the production tool cost. This is particularly useful when component design is still being refined before production tooling is committed.

Tooling ownership depends on the commercial arrangement. In most cases where the client pays for tooling development, the tool is the client's asset and will be transferred if requested. Tooling ownership and transfer terms are explicitly stated in our quotation and purchase order documentation.
